Still EGU 18
Sprężyna gazowa 400N Still 4475027
Kod produktu:10716
Dostępność:
w magazynie
Wysyłka w:24h
Cena netto:
76,36 zł
Cena brutto:
93,92 zł
Opis:
Still EGU 18
Amortyzator gazowy dyszla / Tiller arm gas spring
Still 4475027
Oryginalny STABILUS 400
N
EGU-710115/710117/710119/710125
EGU-H/0201
EGV
14/16-0248/0250
| Type of application | GAS SPRING |
|---|---|
| Type of gas spring/shock absorber | PUSH TYPE |
| Piston rod diameter D1 (mm) | 8 |
| Strength (N) | 400 |
| Centre distance C1 (mm) | 205 |
| Piston rod length L1 (mm) | 65 |
| Type of connection piston rod side | TYPE D |
| Width of the connection W1a (mm) | 13 |
| Overall length L3a (mm) | 18 |
| Connecting distance L4a (mm) | 13 |
| Mounting thickness Ta (mm) | 3 |
| Ball present | NIE |
| Bushing present | NIE |
| Type of connection piston side | TYPE D |
| Width of the connection W1b (mm) | 15 |
| Diameter of the mounting eye D3b (mm) | 8 |
| Connecting distance L4b (mm) | 17 |
| Mounting thickness Tb (mm) | 5 |
| Ball present | NIE |
| Bushing present | NIE |
